The roasting and/or drying process is uniform throughout operation, with the temperature electronically adjustable. The electric heating system features a modulating mechanism to optimize energy consumption and allow precise temperature control.
The machine includes a smoke-decanting cyclone connected to the roaster, along with a carousel for cooling the roasted nuts and cleaning them after roasting.
Available in the ECO version or the PRO version, which includes a cooling and peeling section.
PRODUCTION
- 10-20 kg/batch
(based on the type of nuts used)
DIMENSIONS
- L 840 mm
- W 1700 mm
- H 1350 mm
WEIGHT
- 350 Kg
POWER SUPPLY
- 11 Kw three-phase 400V 50 Hz
(machine available with customizable voltage options)
BATCH DURATION
- Variable from 45 to 60 min, depending on the type of nuts used and the desired level of roasting
The PM60 Pre-grinder is designed for the production of semi-finished products (butter or raw paste), which are used as a base in ball mills for producing nut-based pastes & spreads. The PM60 is designed to work with all types of nuts and/or shelled fruits, such as hazelnuts, almonds, pistachios, and more.
PRODUCTION: 30-60 kg/h variable depending on the type of input product and the desired particle size of the output product.
DIMENSIONS:
- L 700 mm
- W 1000 mm
- H 1400 mm
WEIGHT: 200 kg
POWER SUPPLY: 3 Kw three-phase 400V 50 Hz (machine available with different voltage options)
The Mia Food Tech, MILL-25 Ball Mill Refiner is used to produce and or refine nut pastes such as hazelnut, almond, pistachio, macadamia nut, etc. The MILL25 can also be used to refine chocolate, chocolate substitutes and pastes for ice cream and other confections.
The MILL-25 uses on board cooling to maintain optical temperature. The software ensures precise recipe storage.
Specifications:
- 20/25 kg per batch.
- Dimensions: 80 x 150 x 180 cm
- Weight: 400kg
- Power supply: 4.5 kw, three phase 400V 50hz (optional voltage supply upon request.
Other Capacities:
- MILL-25 20-25 kg/batch
- MILL-50 40-60 kg/batch
- MILL-100 80-120 kg/batch
- MILL-200 150-240 kg/batch
Mia Food Tech produces robust machines specifically for the production of: food supplements, chocolate, pralines, dragees, nougat, brittle, cereal and nut based snacks. The MILL25 is typically ready to ship from Italy.
